Product Description
Electrical Specifications
- Input voltage: 90–305 VAC
- Input current: 0.5 A maximum
- Input frequency: 47–63 Hz
- Power factor: ≥ 0.5
- Output voltage: 12 VDC ±4%
- Output current: 0–1.67 A
- Output power: 20 W
Protection & Safety
- Overcurrent protection: 102–145%
- Short-circuit protection: Hiccup mode, auto-recovery
- Additional protection: Over-voltage, over-load, and short-circuit
- UL listed: UL 879 / UL 8750
- CE-LVD compliant: EN 61347-1, EN 61347-2-13
Environmental Specifications
- IP rating: IP67
- UL environmental suitability: Wet, damp, and dry locations
- Operating temperature: –25°C to +50°C
- Storage temperature: –25°C to +75°C
- Relative humidity: 5–90% RH, non-condensing
